Ther­mo­graphy in Aerospace Industry

Solutions for aerospace through thermal imaging

  • Highest demands on thermal resolutions for safety standards

  • High-speed data acquisition supports monitoring and controlling of fast processes

  • Active heat flow thermography allows testing of modern composite materials and lightweight construction elements

  • Non-destructive material testing reduces expenses of quality control

High Speed Thermography: Start of an airbus

Aerospace Sets Highest Demands on Infrared Camera Systems

Measurement tasks of the aerospace industry often require infrared cameras with very high thermal resolutions of 20 mk and/or high frame rate of 100 Hz and more. Thus, for instance, accurate analyses of aero engine’s thermal behaviour are due to high safety and reliability requirements of the aviation authority. Moreover, quality controls of fuselages, wings and rotor blades of aeroplanes, respectively helicopters, can be carried out in form of efficient fault analyses with infrared camera systems.

thermal imaging of a helicopter

Active Heat Flow Ther­mo­graphy for Testing Composite Mater­ials

Control of an aircraft wing

In particular, the application of light and robust composite materials and other lightweight construction processes of the aerospace industry requires an accurate quality control. For this purpose, active heat flow thermography is increasingly used for the production. Various activation and analysis systems allow efficient fault analyses with fast and high-resolution infrared cameras, even inside materials or the construction.

Case Studies about Aerospace Industry

Public­a­tions of our Customers

Contact to thermography division of InfraTec

Would You Like to Know More?

It is not unusual for tasks to be associated with special requirements. Discuss your specific application needs with our specialists, receive further technical information or learn more about our additional services.

United States
InfraTec infrared LLC1900 West Loop South Suite 155077027 HoustonUNITED STATES

Infrared Cameras by InfraTec Solve Customer Prob­lems

Due to its thermography solutions, InfraTec was able to acquire customers, such as the German Aerospace Center or the European Aeronautic Defence and Space Company (EADS). Contributions to this were high thermal resolutions of the infrared camera series VarioCAM® and the high-end camera series ImageIR®.

thermal imaging of an Airbus A380

Moreover, ImageIR® infrared camera systems can reach a remarkable speed of more than 10 KHz forming the basis of certain process analyses. Apart from the quality of infrared camera systems, engineers have been coping with another great challenge - the cameras’ integration. Thus, clients benefit from customized and optimally integrated solutions which the modern and efficient thermographic software IRBIS® 3 is also part of.

Asso­ci­ated Ther­mo­graphic Auto­ma­tion Solu­tions

Automation InfraTec INDU-SCAN - In-process industrial temperature measurement
Indus­trial Auto­ma­tion

Process Control – INDU-SCAN

Contactless measurement of temperature distributions and profiles with industrial thermographic cameras permits efficient monitoring and control of temperature-dependent processes and procedures within a system-integrated quality assurance programme in industry.

WELD-CHECK by InfraTec
Non-destructive Testing

Welding Inspec­tion – WELD-CHECK

Using pulse thermography, WELD-CHECK enables you a quantitative assessment of the inspected welds.

Thermographic automation brake test bench - Picture Credits: © iStock.com / ktsimage
Non-destructive Testing

High-Speed Rotation Test Bench – TRC

Check for long-life fatigue strength of mechanical components in load tests, using high-end infrared cameras.

E-Lit Cabinet from InfraTec for Infrared Thermography
Non-destructive Testing

Electronic / Semiconductor Testing – E-LIT

Detect inhomogeneous temperature distribution and local power loss during the production using the Lock-in Thermography.

Thermographic Automation Solutions - Automatic object monitoring system IROD
Observation & Investigation

Site Surveillance – IROD

Calibrated measuring cameras offer the option of a completely automated site surveillance by utilising temperature alarms – an approach well beyond the simple and susceptible motion detection systems used elsewhere. With IROD InfraTec offers a scaleable, powerful system solution.

Quality Assurance for Coating Processes | InfraTec / Picture Credits: © iStock.com / Greppe
Indus­trial Auto­ma­tion

Quality Assurance for the Coating of different Materials | InfraTec

Infrared cameras allow the non-destructive and process-synchronous monitoring of coating processes to ensure that the coatings are free of defects as soon as they are applied.

InfraTec thermography - electronics li-ionen-battery - Picture credits: © Fishman64 / Shutterstock.com
Obser­va­tion & Invest­ig­a­tion

Fire Preven­tion – FIRE-SCAN for Li-Ion Batteries

Monitor assembly halls and storage facilities fully automatically 24/7 and detect critical heat sources reliably.

PV-LIT test solution for solar cells
Non-destructive Testing

Photovoltaic Test System – PV-LIT

Get advantages in costing and quality by non-contact thermographic testing of your solar cells and PV-modules.

Automation InfraTec INDU-SCAN - In-process industrial temperature measurement
Indus­trial Auto­ma­tion

Process Control – INDU-SCAN

Contactless measurement of temperature distributions and profiles with industrial thermographic cameras permits efficient monitoring and control of temperature-dependent processes and procedures within a system-integrated quality assurance programme in industry.

WELD-CHECK by InfraTec
Non-destructive Testing

Welding Inspec­tion – WELD-CHECK

Using pulse thermography, WELD-CHECK enables you a quantitative assessment of the inspected welds.

Thermographic automation brake test bench - Picture Credits: © iStock.com / ktsimage
Non-destructive Testing

High-Speed Rotation Test Bench – TRC

Check for long-life fatigue strength of mechanical components in load tests, using high-end infrared cameras.

E-Lit Cabinet from InfraTec for Infrared Thermography
Non-destructive Testing

Electronic / Semiconductor Testing – E-LIT

Detect inhomogeneous temperature distribution and local power loss during the production using the Lock-in Thermography.

Thermographic Automation Solutions - Automatic object monitoring system IROD
Observation & Investigation

Site Surveillance – IROD

Calibrated measuring cameras offer the option of a completely automated site surveillance by utilising temperature alarms – an approach well beyond the simple and susceptible motion detection systems used elsewhere. With IROD InfraTec offers a scaleable, powerful system solution.

Quality Assurance for Coating Processes | InfraTec / Picture Credits: © iStock.com / Greppe
Indus­trial Auto­ma­tion

Quality Assurance for the Coating of different Materials | InfraTec

Infrared cameras allow the non-destructive and process-synchronous monitoring of coating processes to ensure that the coatings are free of defects as soon as they are applied.

InfraTec thermography - electronics li-ionen-battery - Picture credits: © Fishman64 / Shutterstock.com
Obser­va­tion & Invest­ig­a­tion

Fire Preven­tion – FIRE-SCAN for Li-Ion Batteries

Monitor assembly halls and storage facilities fully automatically 24/7 and detect critical heat sources reliably.

PV-LIT test solution for solar cells
Non-destructive Testing

Photovoltaic Test System – PV-LIT

Get advantages in costing and quality by non-contact thermographic testing of your solar cells and PV-modules.

Infrared Cameras for Aerospace Industry

InfraTec Infrared camera
Zoom Cameras

ImageIR® 6300 Z

Image Format(640 x 512) IR-Pixel
Detector typeXBn

InfraTec Infrared camera
High-end Cameras

ImageIR® 8300 hs

Image Format(640 x 512) IR-Pixel
Detector typeT2SLS or InSb

InfraTec Infrared camera
Zoom Cameras

VarioCAM® HD Z

Image Format(1,024 x 768) IR-Pixel
Detector typeUncooled Microbolometer Focal Plane Array

InfraTec Infrared camera
High-end Cameras

ImageIR® 9400 hp

Image Format(2,560 x 2,048) IR-Pixel
Detector typeInSb

InfraTec Infrared camera
System Cameras

ImageIR® 9100

Image Format(1,280 x 1,024) IR-Pixel
Detector typeInGaAs

InfraTec Infrared camera
High-end Cameras

ImageIR® 10300

Image Format(1,920 x 1,536) IR-Pixel
Detector typeInSb

InfraTec Infrared camera
System Cameras

VarioCAM® HD head 900

Image Format(2,048 x 1,536) IR-Pixel
Detector typeUncooled Microbolometer Focal Plane Array

InfraTec Infrared camera
System Cameras

ImageIR® 8100

Image Format(640 x 512) IR-Pixel
Detector typeInGaAs

InfraTec Infrared camera
Compact Cameras

PIR uc 605

Image Format(640 x 480) IR-Pixel
Detector typeUncooled Microbolometer Focal Plane Array

Advant­ages of this Ther­mo­graphy Solu­tions in this Applic­a­tion

Thermography with ImageIR series - HDR feature - Picture credits: © iStock.com / Vershinin M

HDR – Simultaneous Mapping of Wide Temperature Ranges

The High Dynamic Range (HDR) function of the Infrared ImageIR® camera series enables measurement scenarios with extremely different temperatures to be recorded continuously. When recording in HDR mode, multiple thermograms with different integration times and different filters are recorded quickly in succession and compiled into an overall image with a high dynamic range. The measuring range can span up to 1,500 K. Users obtain high-contrast images in a wide temperature range characterized by high measurement accuracy.

InfraTec thermography - High-speed Mode

High-speed Mode – Increase Frame Rate and Sens­it­ivity

Due to the binning technology, infrared cameras have two speed modes – the standard mode and the high-speed mode, in which the frame rate increases more than three times. The field of view remains constant in both modes, so the scene captured by the camera does not change. In high-speed mode, the thermal resolution also increases by a factor of two.

HighSense for thermographic camera series ImageIR®

High­Sense – Always the Optimal Camera Setting

Thanks to HighSense, ImageIR® users have the option of setting up individual measuring ranges based on the factory calibration that best suit the respective task. Depending on the measuring task, the required temperature range can be selected and the optimum integration time for this purpose is calculated – or one decides to proceed in reverse order. Thus, the calibration can be retained even in the case of changed integration times.

ImageIR filter wheel replacement

Multispectral Feature

The multispectral feature makes it possible to record sequences with constantly changing spectral filters. Images are recorded synchronously with a rapidly rotating filter wheel equipped with the filters. It may be possible to switch between up to seven filters, depending on the version. Due to this the multispectral measurement can be optimised to suit the measuring task if the preset ranges are unsuitable. The integration times can be adapted within the limits calibrated for this filter.

Thermografie-Kameraserie ImageIR® mit neuer 10 GigE-Schnittstelle

10 GigE Inter­face for a Strong Increase in Output

The 10 Gigabit Ethernet interface of the high-end camera series ImageIR® opens this extremely fast transmission standard with a NIC specially developed by InfraTec. This works with optical or electrical transceiver modules that are easy to change and are called SFP+.

InfraTec glossary - ImageIR® mobile wireless camera remote control

Mobile Wire­less Camera Remote Control

Stationary camera systems are usually used PC-controlled. Alternatively, InfraTec offers a solution that makes the operation of the camera system even more versatile. An additional tablet PC is attached to the camera housing, which enables wireless control of all camera functions. The display solution allows access to all functions of the IRBIS® online control and acquisition software, delivered together with the camera.

InfraTec glossary - Rotating filter- und aperture wheel

Separate Filter & Aper­ture Wheel – Spec­tral Ther­mo­graphy

The combination of a separate filter and aperture wheel, allowing a total of 35 freely selectable combinations, is prerequisite for a universal application in measurement tasks with high object temperatures and in the field of spectral thermography. The neutral density filters used for signal attenuation or the combination of spectral filters and apertures reliably prevent interference effects.

InfraTec Service Calibration Rig

Auto Calibration

The Auto Calibration option expands the HighSense function to include automatic, dynamic adaptation of the integration time. This ensures the utmost temperature measuring accuracy and an optimised signal-to-noise ratio throughout the process. The wellfill of a detector is usually optimal in certain areas of the dynamic range. If the measured object signal is outside theses or user-specified limits, the integration time is readjusted.

InfraTec Glossary Motorfocus

Motor Focus for ImageIR® Full Lenses – More Comfort

All interchangeable standard lens systems of the ImageIR® series can be combined with a motor focus unit, which is controlled by the camera operating software. It enables precise, remote and fast focusing. In addition, an autofocus function is available which operates reliably even with low image contrasts.

Thermal image during ignition of an airbag  Image Small

Window Mode (Subwin­dowing) – Capture of Rapid Sequences

The thermal imaging camera can be operated in full, half, quarter and sub mode. With the camera control software, it is possible to use the extended subwindowing function. Using click-and-drag, freely definable sections can be set up quickly and conveniently. A defined sub-frame of the detector is picked out to achieve these extremely high refresh rates.

InfraTec Service - thermography lenses

High‐performance Full Optics

High quality precision lenses allow the adaptation of the image geometry to almost every measuring situation. Its performance parameters are calibrated with respect to functionality, quality and flexible application. Due to proper IR-transparent lens materials and high-precision antireflexion coating, the lenses are optimised for different spectral ranges.

InfraTec thermography - Geometrical Resolution

Geomet­rical Resol­u­tion – Effi­cient Analysis of Complex Assem­blies

InfraTec's infrared cameras with cooled and uncooled detectors have native resolutions up to (1,920 × 1,536) IR pixels. Spatially high-resolution thermograms ensure that components and assemblies are imaged down to the smallest detail and thus defects can be reliably detected and precisely localised.

InfraTec thermography - Thermal resolution

Thermal Resol­u­tion – Determ­in­a­tion of Differ­ences of Only a Few Millikelvin

For detection of small temperature changes InfraTec's infrared cameras offer thermal resolutions up to < 15 mK in real-time operation. By using the Lock-in Thermography method it is possible to further increase this resolution significantly. For this purpose test objects are periodically excited and non-destructively examined for defects and irregularities.

Integ­rated Trigger / Process Inter­face and Inter­faces – Digit­ally Controlling of a Infrared Camera and External Devices

The internal trigger interface guarantees highly precise, repeatable triggering. Each of the two configurable digital inputs and outputs are used to control the camera or to generate digital control signals for external devices. In this way, for example, the operation of a printed circuit board and the interval of a measurement can be synchronised.

The selection of different camera interfaces allows the processing of analog data, such as the voltage directly through the camera and thus the insertion of this information into the thermal image data. Relevant variables can be included in the evaluations with the software, which makes it easier to draw conclusions about the causes of temperature changes.

Thermography with ImageIR series - HDR feature - Picture credits: © iStock.com / Vershinin M

HDR – Simultaneous Mapping of Wide Temperature Ranges

The High Dynamic Range (HDR) function of the Infrared ImageIR® camera series enables measurement scenarios with extremely different temperatures to be recorded continuously. When recording in HDR mode, multiple thermograms with different integration times and different filters are recorded quickly in succession and compiled into an overall image with a high dynamic range. The measuring range can span up to 1,500 K. Users obtain high-contrast images in a wide temperature range characterized by high measurement accuracy.

InfraTec thermography - High-speed Mode

High-speed Mode – Increase Frame Rate and Sens­it­ivity

Due to the binning technology, infrared cameras have two speed modes – the standard mode and the high-speed mode, in which the frame rate increases more than three times. The field of view remains constant in both modes, so the scene captured by the camera does not change. In high-speed mode, the thermal resolution also increases by a factor of two.

HighSense for thermographic camera series ImageIR®

High­Sense – Always the Optimal Camera Setting

Thanks to HighSense, ImageIR® users have the option of setting up individual measuring ranges based on the factory calibration that best suit the respective task. Depending on the measuring task, the required temperature range can be selected and the optimum integration time for this purpose is calculated – or one decides to proceed in reverse order. Thus, the calibration can be retained even in the case of changed integration times.

ImageIR filter wheel replacement

Multispectral Feature

The multispectral feature makes it possible to record sequences with constantly changing spectral filters. Images are recorded synchronously with a rapidly rotating filter wheel equipped with the filters. It may be possible to switch between up to seven filters, depending on the version. Due to this the multispectral measurement can be optimised to suit the measuring task if the preset ranges are unsuitable. The integration times can be adapted within the limits calibrated for this filter.

Thermografie-Kameraserie ImageIR® mit neuer 10 GigE-Schnittstelle

10 GigE Inter­face for a Strong Increase in Output

The 10 Gigabit Ethernet interface of the high-end camera series ImageIR® opens this extremely fast transmission standard with a NIC specially developed by InfraTec. This works with optical or electrical transceiver modules that are easy to change and are called SFP+.

InfraTec glossary - ImageIR® mobile wireless camera remote control

Mobile Wire­less Camera Remote Control

Stationary camera systems are usually used PC-controlled. Alternatively, InfraTec offers a solution that makes the operation of the camera system even more versatile. An additional tablet PC is attached to the camera housing, which enables wireless control of all camera functions. The display solution allows access to all functions of the IRBIS® online control and acquisition software, delivered together with the camera.

InfraTec glossary - Rotating filter- und aperture wheel

Separate Filter & Aper­ture Wheel – Spec­tral Ther­mo­graphy

The combination of a separate filter and aperture wheel, allowing a total of 35 freely selectable combinations, is prerequisite for a universal application in measurement tasks with high object temperatures and in the field of spectral thermography. The neutral density filters used for signal attenuation or the combination of spectral filters and apertures reliably prevent interference effects.

InfraTec Service Calibration Rig

Auto Calibration

The Auto Calibration option expands the HighSense function to include automatic, dynamic adaptation of the integration time. This ensures the utmost temperature measuring accuracy and an optimised signal-to-noise ratio throughout the process. The wellfill of a detector is usually optimal in certain areas of the dynamic range. If the measured object signal is outside theses or user-specified limits, the integration time is readjusted.

InfraTec Glossary Motorfocus

Motor Focus for ImageIR® Full Lenses – More Comfort

All interchangeable standard lens systems of the ImageIR® series can be combined with a motor focus unit, which is controlled by the camera operating software. It enables precise, remote and fast focusing. In addition, an autofocus function is available which operates reliably even with low image contrasts.

Thermal image during ignition of an airbag  Image Small

Window Mode (Subwin­dowing) – Capture of Rapid Sequences

The thermal imaging camera can be operated in full, half, quarter and sub mode. With the camera control software, it is possible to use the extended subwindowing function. Using click-and-drag, freely definable sections can be set up quickly and conveniently. A defined sub-frame of the detector is picked out to achieve these extremely high refresh rates.

InfraTec Service - thermography lenses

High‐performance Full Optics

High quality precision lenses allow the adaptation of the image geometry to almost every measuring situation. Its performance parameters are calibrated with respect to functionality, quality and flexible application. Due to proper IR-transparent lens materials and high-precision antireflexion coating, the lenses are optimised for different spectral ranges.

InfraTec thermography - Geometrical Resolution

Geomet­rical Resol­u­tion – Effi­cient Analysis of Complex Assem­blies

InfraTec's infrared cameras with cooled and uncooled detectors have native resolutions up to (1,920 × 1,536) IR pixels. Spatially high-resolution thermograms ensure that components and assemblies are imaged down to the smallest detail and thus defects can be reliably detected and precisely localised.

InfraTec thermography - Thermal resolution

Thermal Resol­u­tion – Determ­in­a­tion of Differ­ences of Only a Few Millikelvin

For detection of small temperature changes InfraTec's infrared cameras offer thermal resolutions up to < 15 mK in real-time operation. By using the Lock-in Thermography method it is possible to further increase this resolution significantly. For this purpose test objects are periodically excited and non-destructively examined for defects and irregularities.

Integ­rated Trigger / Process Inter­face and Inter­faces – Digit­ally Controlling of a Infrared Camera and External Devices

The internal trigger interface guarantees highly precise, repeatable triggering. Each of the two configurable digital inputs and outputs are used to control the camera or to generate digital control signals for external devices. In this way, for example, the operation of a printed circuit board and the interval of a measurement can be synchronised.

The selection of different camera interfaces allows the processing of analog data, such as the voltage directly through the camera and thus the insertion of this information into the thermal image data. Relevant variables can be included in the evaluations with the software, which makes it easier to draw conclusions about the causes of temperature changes.

Asso­ci­ated Indus­tries & Applic­a­tions

thermal imaging for material testing

Material Testing

Save time and costs by non-destructively testing components with infrared camera systems by InfraTec.

thermal imaging in electronics

Elec­tronics & Elec­trical Engin­eering

Measure temperature distributions of smallest electronic components with infrared cameras.

All branches and application areas
