Infrared camera compactIR 400 from InfraTec
  • Detector Format

    High resolution thermal images for temperature measurement

  • High-resolution 5.6" TFT Display

    Representation of the images in native resolution; 170° rotatable and 280° revolvable, daylight suited

  • Protection Degree

    Constant excellent optical and metrological performance even in harsh industrial environments

  • Thermal Resolution

    Precise detection of smallest temperature differences

  • Easy Handling

    The handheld compactIR 400 thermographic camera extends the segment of the entry level cameras by a unique detector format of (400 × 300) IR pixels. The geometrical resolution exceeds those of cameras with standard formats by 1.6 times and means less work for users during the measurements. Apart from the detector format, the thermal resolution also achieves a level that stands out among cameras of this performance class. Temperature differences of 0.045 K can be detected reliably.

  • Simple and Convenient Operation

    You can see how easily the compactIR 400 can be operated, for example, when taking overhead thermal images or when inspecting objects that are difficult to access. The lens unit can be tilted up to 70° and thus simplifies work considerably when inconvenient angles impair the perfect shot of a subject. If you want to see whether your shot was successful, this is indicated by the 5" colour TFT display with (1,280 × 720) pixels, which also serves as a touchscreen and is rotable up to 180° and revolvable up to 270°. Thanks to this flexibility, the camera is ideally suited for use in the maintenance of mechanical and electrical installations and in building thermography.

  • Data Evaluation

    The analysis and evaluation of measurement results can be carried out just as conveniently. Users, for example, can generate reports in PDF format already on the camera, transfer them to a printer via a WLAN interface and print them out immediately. The thermographic IRBIS® 3 software family developed by InfraTec is suitable for more detailed inspections.

Technical Specifications

Spectral range (8 … 14) µm
Pitch 25 µm
Detector Uncooled Microbolometer Focal Plane Array
Detector format (400 × 300)
Temperature measuring range (-20 … 800) °C, to 2,000 °C*
Measurement accuracy ± 2 °C or ± 2 %
Temperature resolution @ 30 °C 0.045 K
Frame rate 60 Hz, 9 Hz*
Storage media SDHC Card, 12 GB internal memory
Focus Motor-driven, manual, autofocus
Zoom Up to 4×
Digital colour video camera 5 Megapixels
Interfaces Micro-USB, Mini-HDMI, WLAN
Tripod adapter 1/4" photo thread
Power supply AC adapter, Lithium-Ion battery
Integrated microphone and speaker Yes
Laser range finder* Yes
Display 5" colour TFT display (1,280 × 720) pixels, 170° rotatable and 280° revolvable, touchscreen
Colour viewfinder* (1,280 × 960) pixels
Single-handed operation Yes
Storage and operation temperature (-40 … 70) °C, (-15 … 50) °C
Protection degree IP54
Impact strength/vibration resistance in operation 25 G (IEC 68 - 2 - 29), 2 G (IEC 68 - 2 - 6)
Dimensions; weight (140 × 206 × 114) mm, 1.15 kg without Lithium-Ion battery
Automatic functions Autofocus, temperature level and temperature range, alarm: visual and acoustic
Measurement functions Global hot / cold spot display, center spot, 5 free choosable, movable measurement fields (line, rectangle, circle, ellipse)
Further functions WLAN print, WLAN remote control, transmission of live images, internal report generator
Analysis and evaluation software* IRBIS® 3
Depending on model
Dimensions of the compactIR

Field of View Calculator

Check the geometrical resolution of our infrared cameras for your application.

Each measurement or testing task has its own characteristic basic conditions. For getting optimal results camera, detector and lens have to be perfectly matched to one another. The field of view calculator helps you to determine the appropriate combination.
