  3. Thermography in Mechanics

Thermography in Mechanics

Precise Inspection of Mechanical Components with Infrared Cameras

  • Visualize mechanical stress: Thermography detects friction, tension, and compression through temperature changes

  • Early fault detection: High-resolution thermal imaging reveals issues before visible damage occurs

  • Analyze fast-moving processes: High frame rates capture dynamic motion in real time

  • Engineered for tough environments: IP67-rated cameras with optional protection for extreme conditions

Asset inspections of an air compressor
Asset inspections of a feed pump
thermal imaging mechanical assembly bearing
0 | 4
Thermal imaging of a mount
Thermal imaging of a mount

Acquis­i­tion of Temper­ature Changes Caused by Draft, Pres­sure or Fric­tion During Oper­a­tion

Mechanical components get loaded by pressure, draft or friction during operations. Those load types will all result in an increased temperature. Like this the running of a spindle will result in friction even though being well lubricated. If the spindle is not well positioned the friction will even increase. Infrared camera systems provide a fast overview of the status of the operation long before indications can be seen without such a device.

Ther­mo­graphy Allows Inspec­tions from a Safe Distance

The non-contacting nature of the thermographic measurements is a big advantage. Maintenance personnel can inspect rotating or other fast moving machine parts from outside a dangerous zone. Inspections are additionally eased up as a visualisation of the inspected area is provided.

Thereby, in case of emergency, first actions can be taken even before any profound analysis of the data has been carried out. Preset temperature thresholds for alarming and other personalized settings also help to get maintenance teams productive in very short time.

Thermal imaging of a diesel engine
Thermal imaging of a diesel engine
Thermographic control of an engine
Thermographic control of an engine

Fast Move­ments Can Be Resolved by Infrared Camera Systems with High Frame Rates

Many mechanical movements run at high speeds. Infrared camera systems should be able to resolve such movements to selectively detect faults. Frame rates of up to 240 Hz in full frame mode of the inspection cameras out of the VarioCAM® High Definition series series or up to 105,000 Hz with the ImageIR® camera series provide with exactly this advantage. Combined with sequence analysis tools of the thermographic software IRBIS® 3 smallest faults can be found right in the moment of emergence and subsequently those faults can be eliminated.

Advant­ages of this Ther­mo­graphy Solu­tions in this Applic­a­tion

MicroScan feature ImageIR

Micro­Scan – Quad­ruple the Image Format

Behind the function is a fast-rotating MicroScan wheel, which is integrated into the camera. It ensures that four different individual exposures are taken per wheel revolution, which are offset laterally by half a pixel each. In this way, thermography achieves a new quality due to thermal images providing a quadrupled spatial resolution.

InfraTec glossary about motor focus

Motor Focus for ImageIR® Full Lenses – More Comfort

All interchangeable standard lens systems of the ImageIR® series can be combined with a motor focus unit, which is controlled by the camera operating software. It enables precise, remote and fast focusing. In addition, an autofocus function is available which operates reliably even with low image contrasts.

InfraTec thermography - Geometrical Resolution

Geomet­rical Resol­u­tion – Effi­cient Analysis of Complex Assem­blies

InfraTec's infrared cameras with cooled and uncooled detectors have native resolutions up to (2,560 × 2,048) IR pixels. Spatially high-resolution thermograms ensure that components and assemblies are imaged down to the smallest detail and thus defects can be reliably detected and precisely localised.

infrared camera VarioCAM HD head of InfraTec

High-quality Light Metal Housing

The very robust light metal housing is available with the protection degree IP67 and protects the camera against mechanical and thermal stress. In conjunction with protection degree preserving LEMO® connectors, it is excellently suited for use in harsh industrial environments. For applications under extreme environmental conditions, suitable protective housings are also available, e.g. made from stainless steel, which can optionally be equipped with a cooling and heating system.

Thermal image during ignition of an airbag  Image Small

Window Mode (Subwin­dowing) – Capture of Rapid Sequences

The thermal imaging camera can be operated in full, half, quarter and sub mode. With the camera control software, it is possible to use the extended subwindowing function. Using click-and-drag, freely definable sections can be set up quickly and conveniently. A defined sub-frame of the detector is picked out to achieve these extremely high refresh rates.

MicroScan feature ImageIR

Micro­Scan – Quad­ruple the Image Format

Behind the function is a fast-rotating MicroScan wheel, which is integrated into the camera. It ensures that four different individual exposures are taken per wheel revolution, which are offset laterally by half a pixel each. In this way, thermography achieves a new quality due to thermal images providing a quadrupled spatial resolution.

InfraTec glossary about motor focus

Motor Focus for ImageIR® Full Lenses – More Comfort

All interchangeable standard lens systems of the ImageIR® series can be combined with a motor focus unit, which is controlled by the camera operating software. It enables precise, remote and fast focusing. In addition, an autofocus function is available which operates reliably even with low image contrasts.

InfraTec thermography - Geometrical Resolution

Geomet­rical Resol­u­tion – Effi­cient Analysis of Complex Assem­blies

InfraTec's infrared cameras with cooled and uncooled detectors have native resolutions up to (2,560 × 2,048) IR pixels. Spatially high-resolution thermograms ensure that components and assemblies are imaged down to the smallest detail and thus defects can be reliably detected and precisely localised.

infrared camera VarioCAM HD head of InfraTec

High-quality Light Metal Housing

The very robust light metal housing is available with the protection degree IP67 and protects the camera against mechanical and thermal stress. In conjunction with protection degree preserving LEMO® connectors, it is excellently suited for use in harsh industrial environments. For applications under extreme environmental conditions, suitable protective housings are also available, e.g. made from stainless steel, which can optionally be equipped with a cooling and heating system.

Thermal image during ignition of an airbag  Image Small

Window Mode (Subwin­dowing) – Capture of Rapid Sequences

The thermal imaging camera can be operated in full, half, quarter and sub mode. With the camera control software, it is possible to use the extended subwindowing function. Using click-and-drag, freely definable sections can be set up quickly and conveniently. A defined sub-frame of the detector is picked out to achieve these extremely high refresh rates.

Event On Demand

Effi­cient Material Testing – Non-destructive and Contact­less

  • Theoretical background – mechanical force, stress and temperature Methods for analysis

  • Examples from practice with application samples – elastic periodical load test and fatigue test

  • Short overview about InfraTec products

Request Recording

Contact to thermography division of InfraTec

Would You Like to Know More?

It is not unusual for tasks to be associated with special requirements. Discuss your specific application needs with our specialists, receive further technical information or learn more about our additional services.
