  3. VarioCAM® HDx head S
Universal Infrared Camera for Fixed Installation

Vari­oCAM® HDx head S

The VarioCAM® HDx head S is a state-of-the-art and very compact radiometric thermographic camera designed for stationary use.

  • High-performance detector in (640 × 480) IR pixels format

  • GigE-Vision interface for camera control and data acquisition

  • Precise and highly repeatable measurements with ± 2 % measurement accuracy

Infrared camera VarioCAM® HDx head S front view
Thermography human medicine with VarioCAM® HDx head S
Infrared camera VarioCAM® HDx head S side view
Infrared camera VarioCAM® HDx head S rear side
Notebook with thermal image
0 | 5
InfraTec Infrared camera
InfraTec-icon-detector-640x480
Detector Format

High resolution thermal images for temperature measurement

InfraTec Icon Vollbildfrequenz 60 Hz
Frame Rate

Precise detection of fast temperature changes

infratec-icon-40 mK
Thermal Resolution

Precise detection of smallest temperature differences

InfraTec-icon-messgenauigkeit-2
Measurement Accuracy

Precise and highly repeatable measurements

infraTec icon optics
Complete Optical Assortment

Adaptation of the image geometry to almost every measuring situation

High-preci­sion Calib­ra­tion of Infrared Cameras Enables for High Accuracy of Meas­ure­ments

The infrared camera VarioCAM® High Definition is calibrated using special algorithms. The specially developed calibration algorithm, with more than just a few calibration curves, is used for compensation of temperature fluctuations. Therefore, highest measuring accuracy and repeatability even at changing environmental temperatures is ensured. The exceptional high measuring accuracy can be reached across a wide temperature range.

Compre­hensive Range of Applic­a­tions

Application-specific configuration of this easy-to-use thermographic camera allows it to be used for surveillance tasks where only small installation spaces are available and continuous operation and automatic operation are required. Its high accuracy of measurement, a comprehensive range of precision lenses and the universal GigE Vision interface concept for digital real-time thermographic data acquisition allow the thermographic camera to be used in a wide variety of applications.

The VarioCAM® HDx head S becomes an universally applicable thermography system, due to various accessories such as protective housings for outdoor applications and various software packages for data acquisition, further processing and documentation.

Contact to thermography division of InfraTec

Would You Like to Know More?

It is not unusual for tasks to be associated with special requirements. Discuss your specific application needs with our specialists, receive further technical information or learn more about our additional services.

United States
InfraTec infrared LLC1900 West Loop South Suite 155077027 HoustonUNITED STATES

Tech­nical Specific­a­tions

Spectral range(7.5 … 14) µm
DetectorUncooled Microbolometer Focal Plane Array
Detector format (IR pixels)(640 x 480)
Temperature measuring range(-40 ... 600) °C
Measurement accuracy± 2 °C or ± 2 %
Temperature resolution at 30 °CUp to 0,04 K
Frame rateFull frame: 30 Hz (640 × 480); Sub frame*: 60 Hz (384 × 288)
Window modeYes

* Depending on model

** In selected measurement ranges

Field of View Calculator for Your Measurement Task

Configure Your Camera System

Each measurement or testing task has its own characteristic basic conditions. For getting optimal results camera, detector and lens have to be perfectly matched to one another. The field of view calculator helps you to determine the appropriate combination.

infrared camera FOV
Software

Fast and Detailed Analysis Using the Integrated IRBIS® 3 Software Package

The efficiency of an infrared camera significantly depends on its data analysis software. As a standard, the thermography software package IRBIS® 3 is included in each camera delivery. This software gives a fast, precise and detailed evaluation of obtained thermograms and sequences. With this, and the copy & paste function in all WINDOWS programmes a good basis is provided for comprehensive development work.

Read more about ther­mo­graphy soft­ware IRBIS® 3

Analysis Software of Software Family IRBIS® 3

Accessories

Breakout box
Data Transfer

Breakout box

Available forVarioCAM® HDxVarioCAM® High Definition
540.00 $

plus shipping costs and legal VAT (if applicable)**

Car power supply
Power Supply

Car power supply 3 m

Available forVarioCAM® HDxVarioCAM® High Definition
220.00 $

plus shipping costs and legal VAT (if applicable)**

Car power supply
Power Supply

Car power supply 5 m

Available forVarioCAM® HDxVarioCAM® High Definition
240.00 $

plus shipping costs and legal VAT (if applicable)*

Charging unit for Li-Ion batteries
Power Supply

Charging unit for Li-Ion batteries

Available forVarioCAM® HDxVarioCAM® High DefinitionVarioCAM® hr

plus shipping costs and legal VAT (if applicable)**

GigE cable
Data Transfer

GigE cable 10 m

Available forVarioCAM® HDxVarioCAM® High Definition
150.00 $

plus shipping costs and legal VAT (if applicable)**

GigE cable
Data Transfer

GigE cable 3 m

Available forVarioCAM® HDxVarioCAM® High Definition
130.00 $

plus shipping costs and legal VAT (if applicable)**

GigE cable
Data Transfer

GigE cable 5 m

Available forVarioCAM® HDxVarioCAM® High Definition
140.00 $

plus shipping costs and legal VAT (if applicable)**

Li-Ion battery
Power Supply

Li-Ion battery (7.2 V, 32 Wh)

Available forVarioCAM® HDxVarioCAM® High DefinitionVarioCAM® hr
200.00 $

plus shipping costs and legal VAT (if applicable)**

infrared camera equipment lightweight tripod
Miscellaneous

Lightweight tripod

Available forVarioCAM® HDxVarioCAM® High DefinitionVarioCAM® hr
510.00 $

plus shipping costs and legal VAT (if applicable)**

Microscope tripod
Miscellaneous

Microscope tripod

Available forVarioCAM® HDxVarioCAM® High DefinitionImageIR®
Power supply
Power Supply

Power supply

Available forVarioCAM® HDxVarioCAM® High Definition
240.00 $

plus shipping costs and legal VAT (if applicable)**

infrared camera equipment rugged tripod
Miscellaneous

Rugged tripod

Available forVarioCAM® HDxVarioCAM® High DefinitionVarioCAM® hr
890.00 $

plus shipping costs and legal VAT (if applicable)**

Table tripod for precise measurements
Miscellaneous

Table tripod for precise measurements

Available forVarioCAM® HDxVarioCAM® High DefinitionVarioCAM® hr
1,280.00 $

plus shipping costs and legal VAT (if applicable)**

infrared camera equipment case
Miscellaneous

Transportation case

Available forVarioCAM® HDxVarioCAM® High DefinitionVarioCAM® hr
440.00 $

plus shipping costs and legal VAT (if applicable)**

Product Flyer

Get all the information you need at a glance in our product flyers

InfraTec VarioCAM HDx head S Flyer
