Infrared Radiometric Zoom Cameras
Radiometric infrared zoom cameras for flexible use without lens changes
High precision in capturing both large objects nearby and small details at long distances
Ideal for industrial monitoring, process control, research as well as security, border protection and surveillance tasks
Supported by InfraTec’s IRBIS® software for intuitive operation, detailed analysis and versatile system integration
Zoom Cameras – Convenient and Long Ranges
Our radiometric infrared zoom cameras allow universal and efficient use with very different or rapidly changing image fields without time-consuming lens changes and the need to interrupt the measurement. They can be used to capture large objects completely from a short distance as well as the smallest objects from a long distance and to measure their temperatures precisely. Their outstanding technical features make them suitable for a wide range of measuring and monitoring tasks.
InfraTec's powerful and intuitive to operate IRBIS® thermography software complements the infrared cameras with a wide range of camera control and editing tools designed to meet different user requirements. It allows detailed analyses in an efficient way.
Detecor Format of Infrared Zoom Cameras
| Detecor fomat (IR pixels) | (640 x 512) | (1,024 × 768) | (1,280 × 1,024) |
| ImageIR® 6300 Z | ◼ | ||
| ImageIR® 8300 Z | ◼ | ||
| ImageIR® 9300 Z | ◼ | ||
| VarioCAM® HD Z | ◼ | ||
| VarioCAM® HD Z security | ◼ |
ImageIR® 6300 Z – Universal Zoom Camera
ImageIR® 6300 Z is a small, lightweight, compact, cooled MWIR system with (640 x 512) IR pixels and a full frame rate of 180 Hz for universal use in thermographic temperature measurements in a wide variety of application fields. It comes with a 7.5× zoom lens integrated as standard, which, in combination with the motorised focus, allows fast and flexible adjustment to different object distances and sizes while maintaining stable image quality and high measurement accuracy.
Super-Zoom Thermal Imaging Systems
The 30× zoom lens of the cooled thermal imaging systems ImageIR® 8300 Z and ImageIR® 9300 Z allows for effortless handling of complex reconnaissance and surveillance tasks such as border protection, vehicle surveillance, environmental monitoring, and animal observation. The outstanding image quality and range are remarkable: land vehicles can be detected up to 18 km away and people up to 15 km away.
High-Resolution Uncooled Zoom Thermography Systems
Our high-resolution thermographic systems VarioCAM® HD Z are radiometric microbolometer cameras with a high-speed motorised 6× infrared zoom lens for the spectral range of (7.5 ... 14) µm. Equipped with an uncooled FPA detector, they deliver brilliant 16-bit thermal images of the highest quality with (1,024 × 768) IR pixels. This combination of thermography in HD format and the continuous zoom lens opens the door for users to continuous thermal monitoring of processes and plants, even from great distances, in unprecedented detail.
Online Events On Demand: Thermal Imaging with Zoom
Unlimited Flexibility in Thermal Imaging with Zoom
Motorized zoom lenses in general
Radiometric zoom lens specialties
Specific motorized zoom camera advantages
Applications for infrared zoom cameras in detail
Long-range Infrared Radiometric Zoom Cameras
To meet the versatile requirements, InfraTec develops thermal imaging zoom cameras in HD quality - with cooled and uncooled detectors. Their main specifications are:
ImageIR® 6300 Z
Cooled (640 × 512) IR pixelsIR detector
(15 … 115) mm or (25 … 170) mm zoom lens with motor focus
Zoom infrared camera series ImageIR® 6300 Z
ImageIR® 8300 Z
Cooled (640 x 512) IR pixel detector
(28 … 850) mm zoom lens with motor focus
Super-zoom infrared camera series ImageIR® 8300 Z
ImageIR® 9300 Z
Cooled (1,280 x 1,024) IR pixel detector
(28 … 850) mm or (50 ... 1,350 ) mm zoom lens with motor focus
Super-Zoom Infrared Camera Series ImageIR® 9300 Z
VarioCAM® HD Z
Uncooled (1,024 x 768) IR pixel microbolometer detector
(25 … 150) mm zoom lens with motor focus
Infrared camera series VarioCAM® HD Z
InfraTec cameras can be integrated into our automated system solution IROD or into the systems of external partners. This extends the possibilty to integrate ITAR-free thermal imaging cameras into various static platforms, ground vehicles, aircraft or ships.
Coastal Protection in the Adriatic Sea
Below pictures illustrate the efficiency of an ImageIR® 9300 Z. Located on an Adriatic radar tower it allows near-field imaging for self-protection, mid-range surveillance of the area adjacent to the tower and remote monitoring of ships near to the coast line. The distance range covers some 25 m to beyond 11 km and even the seaspace to a neighbour island more than 40 km away.
You Need More Information about Zoo-Cameras?
There is zoom-camera matching perfectly your specific requirements. To find out which one it is, just check out all the models in detail.
